Tarot Φ25MM plastic motor mount / Red TL96027-02

Product Description:



DIY carbon nanotubes suitable for Φ25MM six-axis or eight-axis aircraft frame (T810/T960/TL

100B01) and other frame, reinforced PC using imported high-pressure injection, the intensity is higher than conventional products. Back new brushless ESC installed position, the harness to protect card, clip-on design for easy adjustment motor base level. Overall design eye-catching two-tone color has a strong impact on the effect of perspective, provide good visual direction for the body in the air.



Motor mounting pitch: 16MM/19MM/25MM/27MM equilateral triangle installation.



Specifications:

Φ25MM multi-rotor motor mount × 1 (125 × 30 × 52.5MM) 43G

T2.0 motor mounting piece × 1 (74.5 × 51MM) 11G

The M3.0 × 10MM Cup head screw 0.9G × 4

Allen stepped screw the M2.5 × 10MM Cup head 0.8G × 4
